Description
TOPDON TS004 Pro
Handheld thermal imaging monocular with a 19 mm lens for outdoor observation in low light or darkness.
Features
- 384 × 288 infrared sensor at 50 Hz with TISR image enhancement
- Detection range up to 650 yd (594 m); recognition range up to 146 yd (133 m)
- 1×, 2×, 4× and 8× digital magnification with picture-in-picture view
- Five colour palettes and adjustable display brightness
- 32 GB internal storage for thermal images and video
- Wireless phone connection through the TopInfrared app
- IP67 ingress protection and tripod-compatible design
- 5000 mAh battery with up to 10 hours operating time
Technical Specifications
| Infrared resolution | 384 × 288 pixels |
|---|---|
| Frame rate | 50 Hz |
| Focal length | 19 mm |
| Digital magnification | 1×, 2×, 4×, 8× |
| Battery | 5000 mAh |
| Storage | 32 GB built in |
| Protection | IP67 |
| Operating temperature | −10 °C to 45 °C |
| Dimensions | 180 × 64 × 54 mm |
| Net weight | 310 g |
Package Contents
- TS004 Pro thermal imaging monocular
- USB-A to USB-C cable
- Hanging strap
- EVA carrying case
- User manual
